| Diameter (mm) | 324 |
| Inner Diameter (mm) | 213 |
| Length (mm) | 660 |
| Media | Standard Polyester |
| Media Weight (g/m²) | 104 |
| Area (m²) | 10.1 |
| Unit Family | TD / ECB / DFP / PT1001 |
| Top End Cap Design | Open |
| Bottom End Cap Design | Open |
| Earthed | Yes |
| Flame Retardant | No |
| Outer Liner | No |
| End Cap/Liner Material | Galvanized Steel |
| Gasket Position | Above Top End Cap |
| Pleath Height (mm) | 50 |
| Number of Pleats | 323 |
| Max. Temp (°C) | 65 |
| Volume (m³) | 0.16128 |
| Weight (kg) | 5.62 |
